Product Overview
Achieve Precision with a Smart and Versatile Resistance Decade Box
The RBOX-408 Resistance Decade Box offers accurate and reliable resistance measurements with a compact and durable design, making it an essential tool for various applications in troubleshooting, maintenance, education, production line testing, and research.
Exceptional Features of the RBOX-408:
1. Wide Range and High Resolution: Offers a wide range of 1 to 11,111,110 ohms with high resolution (1 ohm per step), providing practical and versatile measurement capabilities.
2. Seven Decades of Resistance: Features seven decades of resistance, allowing precise and flexible measurement adjustments.
3. Slide Switches for Easy Operation: Equipped with slide switches that allow users to simply add or subtract resistance values to achieve the desired measurement.
4. Durable Construction: Built with rugged components and housed in an ABS plastic case for enhanced durability and long-lasting performance.
5. Pocket Size Design: Compact and lightweight design ensures easy portability and convenient use in various environments.
Technical Specifications:
- Range: 1 to 11,111,110 ohms (1 ohm per step)
- Accuracy: 1% resistors used throughout
- Wattage: 1 W
- Internal Stray Resistance: 0.3 ohms max
- Power Supply: None required
- Operating Temperature: 0 to 50℃ (32 to 122℉)
- Operating Humidity: Less than 80% RH
- Weight: 320 g (0.70 lb)
- Dimensions: 14.7 cm x 11.7 cm x 5.1 cm (5.79 x 4.61 x 2.01 inches)
Included Accessories:
- Operation Manual
Optional Accessories:
- Test Alligator Clips (one pair, Model: TL-03)
Versatile Applications:
Ideal for use in general applications, troubleshooting, maintenance, education, vocational training, production line testing, radio and TV services, working standards, research design & development, and physics laboratory work.
Invest in the RBOX-408 Resistance Decade Box for reliable, precise resistance measurements and a robust design that meets the diverse needs of various industries with precision and ease.
Specifications
| Range | 1 to 11,111, 110 ohm ( 1 ohm per step ) |
| Accuracy | 1% resistors used throughout. |
| Wattage | 1 W. * Do not add the voltage over AC 40V or DC 60 V to the output resistance terminals even its stand Wattage is less than 1 W. |
| Internal Stray Resistance | 0.3 ohm max. |
| Power Supply | None |
| Operating Temperature | 0 to 50 °C (32 to 122 °F). |
| Operating Humidity | Less than 80% RH. |
| Weight | 320 g/0.70 lb. |
| Dimension | 14.7 cm x 11.7 cm x 5.1 cm. ( 5.79 x 4.61 x 2.01 inch ). |
| Accessories Included | Operation Manual : 1 PC. |
| Optional Accessory | Test alligator clips, one pair, TL-03 |
